CG-100 Airbag Reset Software V4.0.1.0 Update Feature
Article publi le 15/10/2018
CG100 prog III airbag restore device software released to 4.0.1.0 in October 2018.

CG-100  V4.0.1.0  NEW

(2018.10.13)
http://www.obdii365.com/wholesale/cg100-prog-iii-airbag-restore.html


1. 8-Pin Chip Mileage Adjustment, added support model

  Mitsubishi Lancer 8100B188C 93C86

  Dongfeng Tianlong 3801010-3094YS 93C86

  Dongfeng Fengguang 580 3820010-SA01 24C16

  TOYOTA LEXUS ES200 83800-33P70 93C86

  TOYOTA Sienna 83800-08620-00 93C66

  TOYOTA COLOLLA 83800-YK010 93C46

  TOYOTA LAND CRUISER 200 83800-6AD30-C 93A86

  TOYOTA Levin 83800-F2A10 93C76

  Baojun 310 23893179 24C16

  CHEVROLET CRUZE 13583450 24C16

  BAIC Weiwang M30 ZY-ZB116B-33 A00059881 24C04

  GEELY GX7 451003 24C04

  GEELY Yuanjing ZB1121D 93C56

  GONOW GS6 ZB178A 24C08

  Tangjun A15038200027 24C04

  Yema Yema ZB159C 93C66

  HONDA CRV 78100-T0P-H410 93C76

  HONDA CIVIC 78100-TET-H320 93C86

  HONDA ACCORD 78100-TB2-H110 93C76

  JMC Yusheng GP2-10849-MA 93C86

  KIA Sportage 94003-03060 93S56

  KIA Sportage 94003-03070 93S56

  KIA SOUL 94003-2X010 93S56

  Jinbei 750 3820100-C02-BA 24C04

2. CG100-Airbag, added support model

  Soueast SPC560P40L1 Series

3. CG100-Airbag, model update

  Ford GK29-14B321-AC added wiring diagram

  Great Wall 3658110XKR02A added data

  Mazda KD5H-57K30 correct CPU model, wiring diagram and data

4. CG100-UniProg, added support chip

  NEC R7F701002

  NEC R7F701003

  NEC R7F701006

  NEC R7F701007

  NEC R7F701008

  NEC R7F701009

  NEC R7F701010

  NEC R7F701011

  NEC R7F701012

  NEC R7F701013

  NEC R7F701014

  NEC R7F701015

  NEC R7F701016

  NEC R7F701017

  NEC R7F701018

  NEC R7F701019

  NEC R7F701020

  NEC R7F701021

  NEC R7F701022

  NEC R7F701023

  NEC R7F701024

  NEC R7F701025

  NEC R7F701026

  NEC R7F701027

  NEC R7F701028

  NEC R7F701029

  NEC R7F701030

  NEC R7F701033

  NEC R7F701034

  NEC R7F701040

  NEC R7F701041

  NEC R7F701042

  NEC R7F701043

  NEC R7F701044

  NEC R7F701045

  NEC R7F701046

  NEC R7F701047

  NEC R7F701048

  NEC R7F701049

  NEC R7F701050

  NEC R7F701051

  NEC R7F701052

  NEC R7F701053

  NEC R7F701054

  NEC R7F701055

  NEC R7F701056

  NEC R7F701057

  Fujitsu MB91F591B

  Fujitsu MB91F592B

  Fujitsu MB91F594B

  Fujitsu MB91F596B

  Fujitsu MB91F597B

  Fujitsu MB91F599B

  Fujitsu MB91F59AC

  Fujitsu MB91F59BC

5. CG100-UniProg, the following chips added BOOT storage area

  NEC R7F701A033

  NEC R7F701A233

6. CG100-UniProg, the following chips added CONFIG storage area

  NEC D70F3371

  NEC D70F3372

  NEC D70F3373

  NEC D70F3374

  NEC D70F3375

  NEC D70F3376A

  NEC D70F3377A

  NEC D70F3378

  NEC D70F3379

  NEC D70F3380

  NEC D70F3381

  NEC D70F3382

  NEC D70F3383

  NEC D70F3384

  NEC D70F3385

  NEC D70F3624

  NEC D70F3628

  NEC D70F3634

7. CG100-UniProg, the following chips added OPBT0 storage area

  NEC D70F3522

  NEC D70F3523

  NEC D70F3524

  NEC D70F3525

  NEC D70F3526

  NEC D70F3548

  NEC D70F3549

  NEC D70F3550

  NEC D70F3551

  NEC D70F3552

  NEC D70F3553

  NEC D70F3554

  NEC D70F3555

  NEC D70F3557

  NEC D70F3558

  NEC D70F3559

  NEC D70F3560

  NEC D70F3585

  NEC D70F4000

  NEC D70F4001

  NEC D70F4002

  NEC D70F4003

  NEC D70F4004

  NEC D70F4005

  NEC D70F4006

  NEC D70F4007

  NEC D70F4008

  NEC D70F4009

  NEC D70F4010

  NEC D70F4011

  NEC D70F4012

http://www.obdii365.com/info/cg100-prog-iii-airbag-reset-device-software-update-to-v4010-58607.html
Aucun commentaire - Voir / Ajouter

Program Ford Explorer 2016 smart key with Auro OtoSys IM600
Article publi le 08/10/2018
How to program Ford Explorer 2016 smart key when all keys lost using Auro OtoSys IM100/IM600 key programmer.


Select IMMO>Auto detect->Manual selection->Ford->USA->Explorer->2011-2015->Smart key->Keyless System (CAN)->All smart keys lost
auro-im100-ford-explorer-2016-all-keys-lost-1

auro-im100-ford-explorer-2016-all-keys-lost-2

auro-im100-ford-explorer-2016-all-keys-lost-3

auro-im100-ford-explorer-2016-all-keys-lost-4

auro-im100-ford-explorer-2016-all-keys-lost-5

auro-im100-ford-explorer-2016-all-keys-lost-6

auro-im100-ford-explorer-2016-all-keys-lost-7
This function will delete all learned smart keys. Press YES to continue.
Turn the ignition swicth to ON position with engine OFF.
This procedure will takes 10 minutes.
auro-im100-ford-explorer-2016-all-keys-lost-8

Configuring the system
auro-im100-ford-explorer-2016-all-keys-lost-9
All keys have been erased
auro-im100-ford-explorer-2016-all-keys-lost-10

Insert smart key to be learned into the slot
Learning key
auro-im100-ford-explorer-2016-all-keys-lost-11

1st key learning success
Repeat procedure above to learn next key
Remove the smart key from the slot
auro-im100-ford-explorer-2016-all-keys-lost-12

Insert 2nd smart key to be learned into the slot
auro-im100-ford-explorer-2016-all-keys-lost-13

2nd key learning success
If need to learn more keys, repeat procedure above, otherwise press No.
auro-im100-ford-explorer-2016-all-keys-lost-14

Learning completed.
Aucun commentaire - Voir / Ajouter

Techstream Register Toyota Rav4 2009 Smart Key
Article publi le 29/09/2018
This helps you guys with Toyota Rav4 to register the immobilizer portion of smart keys.

Software: Techstream
Note: You can use the new or old versions.
The latest is Techstream v13
Here, version 9 is used

Equipment: Mini VCI cable
or
or
any diagnostic cable that is confirmed to work with Techstream sw

Car: Toyota Rav 4 2009
Engine: 2GR-FE

Smart code registration process:

Connect the diagnostic cable to the vehicle
Run Techstream
techstream-toyota-rav4-2009-1
Select Division, Model, Year, Engine and specify Options:
techstream-toyota-rav4-2009-2
Car: Toyota Rav 4 2009
Engine: 2GR-FE
Option: 2WD
W/ smart key
Select ECU Smart Key for Smart resetting
techstream-toyota-rav4-2009-3
Click for Utility
techstream-toyota-rav4-2009-4
Then choose Smart Code Registration (classic) in Utility Selection Menu
techstream-toyota-rav4-2009-12
techstream-toyota-rav4-2009-13
The function is used to register the immobilizer portion of smart keys.

Confirm the following conditions:
– Power/engine switch is ON(IG)
– Smart cancel function is OFF

Choose third option:
I am registering keys and have replaced the ID Code Box and Smart ECU or have performed Smart Code Reset
techstream-toyota-rav4-2009-14
Then press Next

Techstream starts to program keys…
To register key touch the Power/Engine Switch with the key – you will hear a signal, and then move the key to the center of car cabin – you will hear a signal once again.
To register the second, third key, etc. – just repeat “touch and move” operations. You have 30 seconds to do this.
techstream-toyota-rav4-2009-15
Smart Code Registration is complete.
techstream-toyota-rav4-2009-16
IMPORTANT:
You can use this Smart Code Registration procedure even ID Code Box and Smart ECU had not been replaced. Both for new and used smart-keys.
Aucun commentaire - Voir / Ajouter

Mitsubishi Space Star Remote Programming with Xtool or Lonsdor
Article publi le 22/09/2018
Today I tried to program a remote key on a  Mitsubishi Space Star year 2014 using Lonsdor K518ISE and Xtool X100 Pad2 key programmer. See what’s worked and failed.
keydiy-universal-key
Using the Keydiy universal remote key

Try with Lonsdor K518
Make a connection
Select Immo function->Mitsubishi->Select from type->Remote
lonsdor-Mitsubishi-Space-Star-1

lonsdor-Mitsubishi-Space-Star-2

lonsdor-Mitsubishi-Space-Star-3
There are only 4 type to choose from, try them one by one
Try Type1->Program Remote, K518 prompts to erase all remotes
lonsdor-Mitsubishi-Space-Star-4
lonsdor-Mitsubishi-Space-Star-5
Then fail to communicate
Try Type 2 to Type 4, all failed
lonsdor-Mitsubishi-Space-Star-6
lonsdor-Mitsubishi-Space-Star-7

lonsdor-Mitsubishi-Space-Star-8

lonsdor-Mitsubishi-Space-Star-9
Then we try the Xtool X100 Pad2
Select Immobilizer function->Mitsubishi->Remote
xtool-x100-Mitsubishi-Space-Star-1

xtool-x100-Mitsubishi-Space-Star-2
There are 6 types we can choose from
Select Type 6->Program remote
xtool-x100-Mitsubishi-Space-Star-3

xtool-x100-Mitsubishi-Space-Star-4
This function will erase all remotes
xtool-x100-Mitsubishi-Space-Star-5
Press each remote LOCK or UNLOCK button 3 times
xtool-x100-Mitsubishi-Space-Star-6
1st remote program ok
xtool-x100-Mitsubishi-Space-Star-7
2nd remote programming success
xtool-x100-Mitsubishi-Space-Star-8
Test the remote control. Working!!

http://www.key-programmer.org/2018/09/22/program-mitsubishi-space-star-2014-remote-with-lonsdor-or-xtool-x100/
Aucun commentaire - Voir / Ajouter

Auro OtoSys IM100 adds BMW CAS1 to CAS3+ key programming
Article publi le 20/09/2018
Auro OtoSys IM100 and IM600 tablet software released to V1.30 on September 18th, 2018.

V1.30    9/18/2018

IMMO_BMW
1. Add CAS4/CAS4+ immobilizer system ECU Renew function.
2. Add three new software version for FEM/BDC system:
Swf1_0000155e_017.110.030,
swf1_00002419_071.010.040
and Sw41_00002419_080.010.010.
3. Add key learning function for CAS1 immobilizer system.
4. Add key generating function for CAS2/3/3+/3++ immobilizer system via programmer.
5. Add new functions for CAS2/3/3+/3++ immobilizer system in system mode,
 including key status , key preprocessing, key repair, Read ISN and key data operation.
6. Add support for CAS Serial Number 9389115, 9389116, 9395656 and 9395657 for CAS3++ immobilizer system.
auro-otosys-im600-update-bmw-immo

Aucun commentaire - Voir / Ajouter
